YW17A Adjustable Wall Mount PIR Infrared Motion Sensor
The YW17A is a wall-mounted PIR infrared motion sensor designed for outdoor and semi-outdoor lighting automation.
With a wide 220° detection angle and adjustable sensor head, it ensures accurate motion detection across entrances, walls, and perimeter areas.
Featuring IP44 protection, adjustable time delay, and ambient light control, YW17A is ideal for energy-efficient security and pathway lighting applications.
Description
Characteristics
Description
Product Overview
The YW17A PIR Infrared Motion Sensor is engineered for reliable outdoor motion detection where wider coverage and directional flexibility are required.
Its adjustable wall-mount design allows precise alignment of the detection zone, making it suitable for building facades, walkways, and corner installations.
With stable performance across varying temperatures and configurable sensitivity settings, YW17A helps reduce false triggers while maximizing lighting efficiency.
OEM and ODM customization is supported, including housing color, packaging, and electrical configuration for project-based requirements.
Technology Specification
PIR Infrared Motion Sensor
Model: YW17A
Power Source: 220–240V AC / 100–130V AC, 50/60Hz
Rated Load:
Max. 1200W (220–240V AC)
800W (100–130V AC)
300W (220–240V AC)
200W (100–130V AC)
Detection Angle: 220°
Detection Distance: Max. 12 m (at <24°C)
Time Delay: 10 sec ±3 sec ~ 7 min ±2 min (adjustable)
Ambient Light Sensitivity: <3–2000 LUX (adjustable)
Installation: Wall mount (adjustable head)
Protection Rating: IP44
Application
Outdoor wall and facade lighting control
Building entrances and exits
Pathways, driveways, and perimeter areas
Residential and commercial security lighting
Energy-saving outdoor lighting systems
Characteristics
• High sensitivity PIR infrared detection
• 360° wide detection coverage
• Adjustable time delay and ambient light control
• Stable and reliable performance
• Suitable for indoor lighting automation
• Energy-saving and automatic switching
• Easy ceiling installation
• Long service life
