YW33A Adjustable PIR Infrared Motion Sensor for Outdoor Lighting
The YW33A is an adjustable PIR infrared motion sensor designed for outdoor lighting control.
It features flexible detection distance, time delay, and ambient light adjustment.
Ideal for security and energy-saving lighting applications in residential and commercial environments.
Description
Characteristics
Description
Product Overview
The YW33A PIR Infrared Motion Sensor is designed for outdoor and semi-outdoor installations requiring reliable motion detection and flexible adjustment.
With an adjustable detection distance of 3 to 12 meters, YW33A allows precise coverage control for different installation heights and areas.
The adjustable light sensitivity and working time make it suitable for both security lighting and automatic illumination systems.
Its robust structure and wide detection angle ensure stable performance in demanding environments.
Technology Specification
PIR Infrared Motion Sensor
Model: YW33A
Power Source: 220–240V AC / 100–130V AC, 50/60Hz
Rated Load:
Max. 1200W (220–240V AC)
800W (100–130V AC)
300W (220–240V AC)
200W (100–130V AC)
Detection Angle: 180°
Detection Distance: 3–12 m (adjustable)
Working Time: 5 sec – 8 min (adjustable)
Ambient Light Sensitivity: < 5–2000 LUX (adjustable)
Installation: Wall mount
Application Type: Lighting control
Application
Outdoor security lighting
Building perimeter illumination
Garden and yard lighting systems
Entrances and exterior walls
Energy-saving automatic lighting solutions
Characteristics
• High sensitivity PIR infrared detection
• 360° wide detection coverage
• Adjustable time delay and ambient light control
• Stable and reliable performance
• Suitable for indoor lighting automation
• Energy-saving and automatic switching
• Easy ceiling installation
• Long service life
